Key features:

• Safety system utilizes the spring-loaded ball-detent principle, ensuring quick and reliable disengagement during overload conditions.
• Functional system: Offers multi-position/automatic re-engagement (W) for convenient operation.
• Adjustment range: Allows torque adjustment within the range of 4-12 Nm, providing flexibility to meet varying application requirements.
• Disengagement torque: Pre-set to 5 Nm, ensuring reliable disengagement during overloads for maximum safety.

Specifications:

• Operable temperature range: -30° C to +100° C (-22° F to +212° F), making it suitable for a wide range of operating environments.

Design and materials:

• Two conical clamping assemblies with six tightening screws each for secure and precise connection.
• Bellows made of high-grade stainless steel provides excellent flexibility and resistance to corrosion, ensuring long-lasting performance.
• Safety system components crafted from hardened steel for enhanced durability and protection against wear and tear.
• Clamping hubs made of lightweight yet sturdy aluminum for optimal strength and reduced rotational inertia.

Bore Specifications:

• Bore D1: Ø12mm H7
• Bore D2: Ø16mm H7
